StarTech.com 4 Port 1U Rackmount USB PS/2 KVM Switch with OSD - 4 Computer(s) - 1 Local User(s) - 1920 x 1440 - 2 x USB - 5 x VGA - 1U - Rack-mountable, Desktop - TAA Compliant
- A dependable 3-year warranty provides peace of mind
- Auto-scan function automatically selects computer sequentially
- Hotkey functions allow easy computer access
- Unique cables for secured connection
- OSD security option allows certain PCs to be password protected from unauthorized use
- Plug-and-play system configuration
- Keyboard and mouse console is USB interface
- Identifies and selects computers by the names assigned
Product Details
General Information
| VGA | Yes |
| USB | Yes |
| Number of Local Users Supported | 1 |
| Number of VGA Ports | 5 |
| Number of USB Ports | 2 |
| Number of Computers Supported | 4 |
| Number of computers controlled | 4 |
| Keyboard port type | USB, PS/2 |
| Mouse port type | USB, PS/2 |
| Video port type | VGA |
| Console ports | VGA (D-Sub) |
| Console USB ports quantity | 4 |
| USB connector type | USB Type-A |
| DC-in jack | Yes |
| Maximum resolution | 1920 x 1440 pixels |
| Plug and Play | Yes |
| Daisy chain | No |
| Number of users | 1 user(s) |
| Rack mounting | Yes |
| Product colour | Black |
| Rack capacity | 1U |
| Housing material | Steel |
| Hot keys | Yes |
| Built-in display | No |
| On Screen Display (OSD) | No |
| Input voltage | 110-240 V |
| Input current | 0.2 A |
| Output voltage | 9 V |
| Output current | 0.6 A |
| Power consumption (typical) | 5.4 W |
| Power plug type | Type M |
| Operating temperature (T-T) | 5 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Width | 130 mm |
| Depth | 220 mm |
| Height | 43 mm |
| Weight | 1.5 kg |
| Package width | 88 mm |
| Package depth | 410 mm |
| Package height | 212 mm |
| Package weight | 1.7 kg |
| Manual | Yes |
| AC adapter included | Yes |
| Dimensions (WxDxH) | 130 x 220 x 43 mm |
Product Information
| Brand | StarTech |
| Type | KVM Console |
Description
This 4-port USB+PS/2 KVM Switch lets you control multiple PS/2 or USB-controlled computers from a single console (USB keyboard, USB mouse, monitor). The versatile USB PS/2 KVM switch features convenient pushbutton and hot-key control for quick, reliable switching between connected computers. A convenient and straight-forward control solution, the USB PS/2 KVM switch supports both manual and auto-scan modes and simple configuration through the built-in OSD. Designed to ensure maximum space-efficiency, the USB+PS/2 KVM switch features a slim 1U design that fits neatly into a server equipment rack/cabinet and offers rear cable connections to eliminate cable tangles. Backed by 3 year warranty and free lifetime technical support. Rackmount your KVM switch If you’d like to mount this KVM switch to your server rack, StarTech.com offers a 1U Rackmount Bracket (sold separately) that turns this KVM into a rackmountable KVM. The StarTech.com Advantage - Optional rack-mountable bracket - Unparalleled reliability - Ultra-compatible - Powerful features that increase usability
